X08
X08 speaker is a point source full-range speaker with built-in crossover. It's a good choice for restaurant bar, pub, multi function room, conference room, museum and other fixed installations.
The HF driver is with a customized 1.4-inch voice coil composite membrane and with a unique driver protection circuit. The bass adopts tailor-made 8-inch driver with advanced cooling system.
X08 adopts DMF composite materials HF horn technology, ensures premium sound dynamics. The coverage angle is (H°x V°) 80°x 70° and the horn is 90° rotatable, with high precision coverage both horizontally and vertically.
X08 enclosure made of excellent wood, innovative design of compact and multi-purpose enclosure structure, CNC made cabinet, providing clear and powerful sound dynamics. The enclosure can be mounted in multi angles a ccording to the installation needs.
Specifications
| X08 | X12 | X15 | X18S | |
| Frequency Response (-6dB anechoic chamber) |
70Hz-20kHz | 50Hz-20kHz | 45Hz-20kHz | 38Hz-300Hz |
| Rated power(AES) | 200W | 400W | 500W | 1200W |
| Maximum SPL | 123dB | 128dB | 130dB | 133dB |
| Horizontal Coverage Angle(HxV) | 80 ° x 70 ° | 90 ° x 60 ° | 90 ° x 60 ° | --- |
| LF Driver | 1x 8 "Customized driver | 1x 12 "Customized driver | 1x 15 "Customized driver | 1x 18 "Customized driver |
| HF Driver | 1x 1.4 "Customized driver | 1x 1.4 "Customized driver | 1x 1.4 "Customized driver | --- |
| Impedance | 8 Ω( +1,-1) | 8 Ω( +1,-1) | 8 Ω( +1,-1) | 8 Ω( +2,-2) |
| Pole Mount | Base hole Φ35mm | Base hole Φ35mm | Base hole Φ35mm | M20 base Φ35mm |
| Input Connectors | 2x Speakon NL4 connections | 2x Speakon NL4 connections | 2x Speakon NL4 connections | 2x Speakon NL4 connections |
| Cabinet Material | 2x Speakon NL4 connections | 2x Speakon NL4 connections | 2x Speakon NL4 connections | 2x Speakon NL4 connections |
| Cabinet Color | Black/White | Black/White | Black/White | Black/White |
| Dimension (W×H×D) | 226 x450x282mm | 324 x565x335mm | 398 x678x413mm | 500 x700x590mm |
| Net Weight | 9.5Kg | 14.0Kg | 18.5Kg | 44.0Kg |
